1.19 Inch Amoled LCD Display IPS MIPI /SPI Round LCM For Electronic Watch

Product Categories

Shenzhen Ok Smart-Lcm Photoelectric Co., Ltd.

Contact Now

1.19 Inch Amoled LCD Display IPS MIPI /SPI Round LCM For Electronic Watch

Name: 119 Inch Amoled LCD Display IPS MIPI SPI Round LCM For Electronic Watch
Brand: OK
Price: 20.8 USD

Quality 1.19 Inch Amoled LCD Display IPS MIPI /SPI Round LCM For Electronic Watch for sale

Brand Name : OK

Model Number : OK0119

Certification : ISO9001:2005

Place of Origin : Shenzhen China

MOQ : 1pcs

Price : 20.8 USD/PCS

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 1000000 Pcs

Delivery Time : 10-35 working days

Packaging Details : kraft box with master carton or customized design

LCD Type : Amoled 1.19 Inch

Encapsulation Glass outline : Dia 33.22 mm

Dimension outline : 33.22 x 34.72 x 0.68 mm

LTPS Glass outline : 33.22 x 34.72 mm

Number of dots : 390(W) x RGB x 390(H)

Diagonal size : 1.19 inch

Active area : Dia 30.42 mm

Pixel pitch : 78*78 μm

Glass thickness : 0.2 / 0.2 mm

Weight : TBD g

Contact Now

1.19 Inch Amoled LCD Display IPS MIPI /SPI Round LCM For Electronic Watch

1. Features

1.1 Product Applications Smart Watch

1.2 Product Features

Display color	16.7M (RGB x 8bits)
Display format	1.19”(390RGBx390)
Pixel arrangement	Real RGB arrangement
Interface	MIPI /SPI

2. Mechanical Specifications

Dimension outline 33.22 x 34.72 x 0.68 mm

LTPS Glass outline 33.22 x 34.72 mm

Encapsulation Glass outline Φ33.22 mm

Active area φ30.42 mm

Number of dots 390(W) x RGB x 390(H) dots

Diagonal size 1.19 inch

Pixel pitch 78*78 μm

Weight TBD g

Glass thickness (LTPS/encapsulation glass) 0.2 / 0.2 mm

We, Shenzhen OK smart-LCM photoelectric co., Ltd focus on the LCD screen and module for 13 years, high effiency, high ROI building long-term partnership with each other not one-time business.
It would be our most pleasure to be your trusted sourcing partner handing the purchasing, exporting and after-service issue in China, you develop market and promote sales with 100% energy without any worries.

Any inquiry, welcome to contact with us.

1.19 Inch Amoled LCD Display IPS MIPI /SPI Round LCM For Electronic Watch
